Ship Canal Water Quality Project in Seattle Earns Envision Platinum Rating

The Ship Canal Water Quality Project includes a 2.7-mile, 18-ft and 10-in internal-diameter tunnel that will extend from Ballard to Wallingford. Left: Ballard Tunnel Segment. Right: Wallingford Shaft Site. Photos supplied in December 2022 courtesy Seattle Public Utilities.

Seattle Public Utilities’ Ship Canal Water Quality Project has been awarded Envision Platinum for sustainability. This project had verified achievements across several areas of the Envision framework, and in particular, it will bring significant water quality improvements to prevent 75 million gallons of polluted stormwater and sewage from entering the region’s waterways on average each year.

Public Utilities and King County’s Wastewater Treatment Division are completing an underground storage tunnel to reduce the amount of polluted stormwater runoff and sewage that flows in the Lake Washington Ship Canal, Salmon Bay, and Lake Union from the sewer system.

In some parts of Seattle (as with many other places), stormwater and sewage share a set of pipes — a combined sewer system which, during heavy storm/rain events, overflows when pipe capacity is exceeded. Untreated sewage and stormwater then flow directly into the Ship Canal, posing public health concerns and harming fish, wildlife, and the environment. The Ship Canal Water Quality Project is crucial for keeping the waterways clean and protecting human health and the environment over the long term.

This project is funded in part by the Washington State Department of Ecology and the Environmental Protection Agency through the State Revolving Fund and Water Infrastructure Finance and Innovation Act loans. The project’s 2.7-mile, 18’10”-diameter tunnel will be able to capture and temporarily hold more than 29 million gallons of stormwater and sewage during heavy rains. As the heavy rains subside, flows will be sent to King County’s West Point Wastewater Treatment Plant in Magnolia for treatment.

View the full announcement in our Project Directory.

LAX Automated People Mover Project earns Envision Gold for Sustainability

An electric train system that runs on a 2.25-mile elevated guideway at Los Angeles International Airport (LAX) is the latest recipient of an Envision Gold Award for sustainability from ISI. The Automated People Mover (APM) project will connect six stations, three of which are located inside the Central Terminal Area (CTA) and three outside. LAX broke ground on the APM in March 2019, and the project is scheduled to open for passenger service in 2023.

The APM will provide enhanced connection and an improved user experience for an anticipated 30 million passengers each year. The system will also help alleviate congestion in the surrounding communities.

Quotes

“The LAX Automated People Mover is coming to life right before our eyes as the centerpiece of our multibillion-dollar airport modernization program, with a sharp focus on building a sustainable LAX for the future of our city,” said Justin Erbacci, Chief Executive Officer, Los Angeles World Airports. “This transformative transportation system will remove cars from the road, help ease traffic congestion around our Central Terminal Area, and create a reliable way for our tens of millions of passengers to access the airport.”

“This project builds on a robust vision for sustainability, entirely transforming the way passengers move around and through Los Angeles International Airport and significantly reducing the reliance on automobiles for ground access, said Melissa Peneycad, ISI managing director. “All that is achieved broadly for community sustainability, quality of life, stakeholder involvement, and energy use on this project make it a well-deserved recipient of the Envision Gold Award.”

The project had Envision verified-achievements in areas such as planning for sustainable communities, improving community quality of life, stakeholder engagement, and use of renewable energy.

View the full announcement in our Project Directory.

Downtown Redmond Link Extension Earns Envision Platinum Award for Sustainability

Downtown Redmond Station construction progress October 11, 2022. Photo courtesy Sound Transit.

Sound Transit’s new light rail project that will bring service to downtown Redmond, Washington, has been awarded an Envision Platinum Award, with sustainable achievements across five areas of Envision. Sound Transit is building the extension with parters who include Jacobs (Lead Design Firm), Stacy and Witbeck/Kuney, a Joint Venture; WSP, Hatch LTK, Hensel Phelps, and Modern Railway Systems.

The Downtown Redmond Link Extension Project (DRLE) is a 3.4-mile light rail extension that includes new surface and elevated guideway structures, stations at Marymoor Village and Downtown Redmond, a parking garage, and associated utility, drainage, environmental, and roadway improvements. Currently under construction, this project will extend Sound Transit’s 2 line from the future Redmond Technology Station providing residents and commuters in Redmond with direct light rail service to Overlake, Bellevue, Mercer Island, downtown Seattle, the University of Washington, Northgate, Lynnwood, SeaTac Airport and Federal Way.

QUOTES:

“Doing this well on the first attempt at Envision verification is testament to Sound Transit’s long and deep commitment to excellence in sustainability. We are proud of this achievement and look forward to continuing our work to provide environmentally friendly public transit that connects people throughout the Puget Sound region to where they live, work and play.”

— Kimberly Farley, Sound Transit Chief System Officer

“SWK and Jacobs are excited to achieve Envision Platinum for the Sound Transit Downtown Redmond Link Extension project. Exceeding the original goal of Envision Silver and earning Envision Platinum recognition is a testament to the collective vision of Sound Transit, WSP, SWK and Jacobs and their pursuit of continual sustainability improvement,. We are very proud to be a part of this tremendous effort to advance more sustainable and resilient infrastructure and deliver a project that adds lasting value to the region.”

— Zach Adams, SWK Deputy Project Manager

“We are pleased to announce an Envision Platinum Award for the Downtown Redmond Link Extension project. The high level of stakeholder engagement, the emphasis on renewable energy sources, and the importance given to protecting the environment during construction are among the sustainable achievements that have set this project apart.”

— Melissa Peneycad, ISI managing director

This award recognizes Envision-verified achievements on this project related to:

— Providing sustainable transportation options;
— Empowering communities through meaningful engagement;
— Using renewable energy;
— Improving the quality and reliability of infrastructure services; and
— Protecting the environment.

View the full announcement in our Project Directory.

York Region’s 2nd Concession Project receives Envision Bronze Award

ISI has awarded an Envision Bronze Award for sustainable infrastructure to the 2nd Concession Project, a major north-south arterial corridor under the jurisdiction of the Regional Municipality of York (York Region). Located in the Town of East Gwillimbury, this is the second project in Ontario to earn an Envision award for sustainability and the first project in the transportation sector in the province to do so.

The project in brief

The 2nd Concession project—the largest project ever undertaken by York Region’s Transportation Services Department—was a necessary investment in infrastructure to accommodate the tremendous growth in York Region and the Town of East Gwillimbury in particular. The six-kilometer corridor, extending from Bristol Road to Queensville Sideroad, crosses the Rogers Reservoir, a popular conservation area and recreational trail in the East Holland River watershed, which the Lake Simcoe Region Conservation Authority manages.

This project widened the 2nd Concession from two lanes to four and included trails, three bridges, retaining walls, active transportation facilities, and stormwater management.

Some of the unique elements of this project included:

—An elevated wooden boardwalk through wetlands and marshes connecting forests with growing residential communities.
—Benches, bike racks, and a flagstone meeting area.
—A wooden-clad pedestrian bridge in the Rogers Reservoir overlooks the historic canal and lock system, which the project protected and preserved.
—Bridges spanning an active rail corridor and the Holland River.
—Curvilinear and terraced tree-patterned retaining walls.
—Dedicated cycle tracks (the first in the Region).

Quotes

“Congratulations to York Region and its project partners on earning an Envision Bronze award for sustainable infrastructure for the 2nd Concession project. This award results from tremendous teamwork, leadership, and community collaboration. Everyone in the area should be proud of this achievement. Protecting and enhancing the corridor area as an important resource for residents was given high priority in the planning and construction of the project, with a context-sensitive design maintaining or improving the natural systems and community quality of life aspects receiving careful attention.”
—  Melissa Peneycad, ISI’s managing director.

“Yesterday was the first time we took our dogs for a walk along 2nd Concession. The view from the bridge is amazing. The viewing platforms on the bridge are a nice touch. The boardwalk for the trail blends in well with the environment. You and your staff have done a wonderful job on this project.”

— R.W. a long-time resident living in the project corridor

This project had verified sustainability achievements in the following areas, among others: meaningful stakeholder engagement; improved infrastructure integration; improved mobility, safety and access; and wetland restoration.

View the full announcement in our Project Directory.

Taylor Yard Bike/Walk Bridge Connects Communities across Los Angeles River and earns Envision Bronze Award for Sustainability

The City of Los Angeles Bureau of Engineering’s Taylor Yard Bikeway and Pedestrian Bridge is one of the newest bridges to span the Los Angeles River. It’s a car-free bridge reserved exclusively for pedestrians and cyclists.

Opened in 2021, this 400-foot-long, 27-foot-wide steel truss box bridge connects the Elysian Valley and Cypress Park communities, located on the south and north sides of the river, respectively. Orange in color to represent the beautiful LA sunsets, the bridge has a distinctive style. It was designed to require minimal supports in the river, reducing the disruption of the natural flow of the river and habitat impacts. The bridge includes lookout platforms for viewers and provides users with improved river access and more green spaces to bike and walk. It was designed to be durable, easy to maintain, and constructed efficiently.

Project Partners

The owner, the City of Los Angeles, worked in close collaboration with several partners on the bridge design and construction, including SPF:architects (Architect), Tetra Tech (Civil Engineer), Arup (Structural Engineer), Hood Design (Landscape), and Ortiz Enterprises (Contractor).

Quotes:

Melissa Peneycad, managing director at the Institute for Sustainable Infrastructure: “The Taylor Yard Bike/Walk Bridge connects communities in an aesthetically pleasing, sustainable way. The bridge enlarges sustainable transportation and recreation options for people in neighboring communities, true to the city’s plans to enhance the river identity and improve mobility. For these reasons and more, ISI is pleased to recognize this project with an Envision Bronze award for sustainability.”

Ted Allen, City Engineer: “The Taylor Yard Pedestrian Bridge is the third pedestrian crossing in recent years that the Bureau of Engineering has completed along this stretch of the Los Angeles River. These bridges are connecting communities and creating safe, car-free ways for people to cross the river. These projects are part of the overall revitalization of the Los Angeles River, and highlight the City’s ongoing commitment to connecting communities and bringing residents more ways to access and enjoy open space.”

View the full announcement in our Project Directory.

New resource! Release of an Envision-verified Project Submission

The most comprehensive project example provided by ISI to date comes from this intermodal transit center project located in the Berryessa district of San Jose, California

For the first time, specific details and Envision documentation from a verified project have been made available as a resource to help other Envision users. This resource includes the Envision scorecard and several Envision credit submittals—including coversheets and supporting documentation—for the Berryessa Transit Center Project, which was awarded Envision Platinum in March 2021.

The project’s owner, Santa Clara Valley Transportation Authority, and the lead Envision firm for the project, Keish Environmental, have graciously granted permission to ISI to release their Envision project submission, and it’s now available as a resource to anyone with an ISI account. A link to the materials can be found on users’ dashboards under “Verification Resources” after logging into the ISI site: https://v4.sustainableinfrastructure.org/login.

Every Envision-verified project is different, with a specific context, requirements, and aspirations that cannot be easily extrapolated to another project. Still, the specificity of an actual project example can be tremendously valuable in adding a further layer of insight and visibility into the verification process.

Applicants are expected to find this resource very instructive, as it makes available the written responses and supporting documentation used to meet Envision requirements during project verification.

“The example provides all the materials submitted by the Berryessa project for seven Envision v3 credits,” notes Kristi Wamstad, ISI’s verification director. “It also includes verifier comments and additional documentation from the project team’s resubmission for the second review. This resource really offers Envision users an authentic insight into the verification process.”

“We are indebted to Santa Clara Valley Transportation Authority and Keish Environmental for granting permission to make available their project submission, as this is easily the most comprehensive project example provided by ISI to date,” said Melissa Peneycad, ISI’s managing director.

Berryessa Transit Center: A stand-out example Envision project

There’s also excitement across the Envision community about the high caliber of the first project to be made public. The Platinum-Awarded Berryessa Transit Center delivered diverse, interrelated benefits for environmental justice, restoration of the natural world, adding public space and amenities, improving local character, improving the community’s long-term sustainability, and more.

As ISI’s award announcement highlighted last year, this intermodal transit center located in the Berryessa district of San Jose, California, is a shining example of integrating sustainability in as much of the project footprint as possible, from EV chargers – to a new, multi-modal trail – to habitat restoration in an urban environment – to a contemplative garden honoring the Muwekma Ohlone Tribe of the San Francisco Bay Area.

“We’re thrilled to have the first Envision-verified project to be shared as a unique resource that can accelerate the use of Envision to evaluate and deliver on sustainability,” said Ann Calnan, Manager of Environmental Programs at Santa Clara Valley Transportation Authority.

“It is an honor to be able to ‘go public’ with a project that I am so proud to have worked on, complete with the supporting documentation, knowing how this may assist other Envision users in preparing their projects for verification,” said Rachael Keish, CEO of Keish Environmental.

ISI hopes the release of materials from the Berryessa Transit Center project will inspire other project teams to make their project documentation public, as sharing actual project examples can accelerate sustainability practices and the use of Envision as a vital tool for accomplishing that.

While the information provided in this resource does not supersede the guidance and requirements established in the Envision Guidance Manual (v3), the Guide to Envision Verification for Applicants, Credit Amendments (v3), and ISI Policies, ISI believes this example project submission offers valuable support to applicants and opens a new window into the verification process.

Questions about this resource, or other resources available to applicants, can be directed to info@sustainableinfrastructure.org.

About the partner organizations

Santa Clara Valley Transportation Authority (VTA)

The Santa Clara Valley Transportation Authority (VTA) is an independent special district that provides sustainable, accessible, community-focused transportation options that are innovative, environmentally responsible, and promote the vitality of the region. VTA is responsible for bus, light rail, and paratransit operations and serves as the county’s congestion management agency implementing specific highway improvement projects and performing countywide transportation planning including bikeways and pedestrian facilities. Visit www.vta.org.

Keish Environmental

Keish Environmental provides sustainability, program/construction management, and environmental compliance services. Founded in 2014, the firm specializes in ensuring regulatory permit conditions, stormwater quality requirements, and environmental document mitigations are implemented in the field to allow smooth project delivery. Sustainability is a core value at the firm and our staff are certified as both LEED and Envision Sustainability Professionals (ENV SPs). The firm’s practical approach to implementation helps projects achieve the highest levels of sustainability, while completing work on budget and on schedule. Keish Environmental is a certified small business. Visit https://keishenv.com.

ISI Releases New Envision Credit Amendments

Developed in collaboration with ISI’s Envision Review Board, two new credit amendments have been approved and are now on ISI users’ dashboards — amendments #008 and #009 (part of the Credit Amendments (v3) consolidated package under “Verification Resources” at https://v4.sustainableinfrastructure.org/login). Users can refer to the resource shown with a red box in the screenshot below:













The Envision guidance manual is the official reference for project assessments. Credit Amendments from ISI modify the manual to clarify how Envision credits are assessed and verified in certain situations encountered by real projects.

As a reminder, ENV SPs and other Envision users should periodically check your dashboard every few months to be sure they have the most up-to-date resources as ISI may add or amend resources at any time.

East Side Coastal Resiliency Project Receives Envision Gold Award for Sustainability

The East Side Coastal Resiliency project uses a series of berms, flood walls, flood gates and raised parklands to create a continuous 2.4-mile barrier to protect 110,000 residents of the Lower East Side in Manhattan from future coastal and tidal flooding.

NYC Department of Design and Construction (DDC) Commissioner Thomas Foley announced Aug. 1 that the East Side Coastal Resiliency (ESCR) Project, which is enhancing parks while creating a 2.4-mile long flexible flood barrier extending from Montgomery Street on Manhattan’s Lower East Side up to Asser Levy Playground at East 25th Street, has been awarded “Envision Gold” for sustainability from ISI.

ESCR is a $1.45-billion climate resiliency project that will provide flood protection and improve open spaces for more than 110,000 New Yorkers, including 28,000 residents in NYCHA housing. This is especially significant for neighborhoods in the ESCR project area that were severely impacted by Superstorm Sandy in 2012. Managed by DDC, the project involves significant upgrades to public open spaces and five parks, including improved waterfront access through reconstructed bridges and entry points. It will also upgrade existing sewer systems to capture and manage precipitation during storms.

Quotes:

NYC Department of Design and Construction Commissioner Thomas Foley: “DDC is honored to bring flood protection and improve open spaces for 110,000 New Yorkers who were affected by Sandy and who live in an area with limited recreational opportunities. DDC and all of City government are taking climate change seriously and targeting our efforts to the communities that need it most. I’d like to thank the Institute for Sustainable Infrastructure for recognizing this project with its Envision Gold Award.”

Mayor Eric Adams: “It is affirmational to be honored for our work to protect New Yorkers from the impacts of climate change. In the face of the biggest environmental threat we all face – we will continue to plan ahead, innovate, and get stuff done for New Yorkers.”

View the full announcement in our Project Directory.

The City of Coral Gables’ Cocoplum 1 Pump Station earns Envision Bronze Award

The Cocoplum 1 Pump Station, owned by the City of Coral Gables, Florida, has earned an Envision Bronze award, recognizing stakeholder involvement and delivery of community benefits, climate resilience, and protection of the surrounding lands.

The upgrades to the wastewater system in this project are the latest example of the infrastructure owner’s commitment to sustainability: the City of Coral Gables has more than 20 public works officials who are Envision Sustainability Professionals (credentialed professionals trained in the use of the Envision sustainable infrastructure framework and rating system), and it has also pledged to use Envision on other city infrastructure projects.

Hazen and Sawyer was the lead Envision firm on this project.  The project partners included Miami-Dade County, Hazen and Sawyer, and David Mancini & Sons, Inc.

The upgrades included replacing the force main and upsizing the capacity of the station pumps, eliminating the need for Pump Station D to repump Cocoplum 1 station flows and improving system reliability. The project also widens an existing bike path along the force main route on Cocoplum Road and installs a sidewalk between Cocoplum Road and Sinsonte Avenue in response to a request from the local Homeowners Association (HOA). Design elements to improve the resilience of the Pump Station include the installation of a backup emergency generator, the use of more durable materials, and the elevation of critical equipment to avoid damage from flooding and sea level rise.

Verified Sustainability Achievements

—Improving overall community quality of life
—Involving stakeholder
—Avoiding natural world impacts
—Increasing project resilience

Quotes

“This is a great Utilities Division accomplishment, but the results will benefit everyone,” explains Jose Saucedo, Senior Project Manager at City of Coral Gables. “We’re very happy for this achievement.”

Melissa Peneycad, ISI’s Managing Director: “Public works projects provide excellent opportunities to address a range of community needs. And this project is no exception. In addition to implementing the necessary upgrades to resolve the initial moratorium and keep the pump station functioning now and well into the future, the project team has also incorporated other elements to improve community livability, such as improving an existing bike lane used by residents, installing a new sidewalk, and ensuring the traditional aesthetic character of the community is preserved by this project.”

View the full announcement in our Project Directory.

Iconic Sixth Street Viaduct in Los Angeles earns Envision Platinum

Photo courtesy of Skanska-Stacy and Witbeck (SSW).

The Sixth Street Viaduct, the largest bridge project in the history of Los Angeles, has earned an Envision Platinum award for sustainability, specifically for addressing community needs, adding significant public space and amenities, and improving community safety and resiliency.

The $588-million project is funded by the Federal Highway Transportation Administration, the California Department of Transportation, and the City of Los Angeles. The City’s Bureau of Engineering, under the leadership of City Engineer Gary Lee Moore and in partnership with the City’s Bureau of Contract Administration, led the development of the new Sixth Street Viaduct Replacement Project.

The new bridge was designed by HNTB Corp, with HNTB the Engineer and Architect of Record, in collaboration with Los Angeles architect Michael Maltzan Associates and Danish architect Dissing+Weitling. Construction of the bridge was delivered through CMGC and led by a joint venture of contractors Skanska-Stacy and Witbeck (SSW).

“The Ribbon of Light,” as the viaduct has been dubbed, opened with a July 9th public celebration held on the viaduct followed by full opening to traffic on July 10th, 2022.

Verified Sustainability Achievements

—Providing much-needed public space and amenities.
—Improving community safety and incorporating alternative modes of transportation into the project’s design.
—Rebuilding an iconic structure.
—Supporting long-term sustainable growth and development.
—Incorporating resiliency into the design.

Quote

“The City of Los Angeles Bureau of Engineering is proud to deliver the largest bridge project in the city’s history,” said Gary Lee Moore, City Engineer. “The new viaduct looks to the future and will unite the community with a multi-model structure that will be a destination point for both residents and visitors. This project is an example of what future infrastructure projects should strive to achieve through collaboration with stakeholders and the delivery of a project that improves community mobility, quality of life, safety and resilience. The Sixth Street Viaduct has achieved these sustainable goals, as shown by the Platinum Envision award.”

View the full announcement in our Project Directory.
